- The Toyota Innova Crysta is a 7- or 8-seater MUV with a 4,735 mm length.
- It has a 1,830 mm width, 1,795 mm height, and 2,750 mm wheelbase.
- The Innova Crysta uses a 2.4-litre diesel engine producing 148 bhp and 343 Nm.
- It gets a 5-speed manual transmission with rear-wheel drive (RWD).
- The MUV has a 55-litre fuel tank and 300-litre boot space.
- Its key features include ABS, airbags, automatic climate control, alloy wheels and a multifunction steering wheel.
The Toyota Innova Crysta is a multi-utility vehicle designed around passenger space, practicality and long-distance use. Its dimensions give it a substantial road presence, while the 2.4-litre diesel engine provides 343 Nm of torque. The Innova Crysta is available in 7- and 8-seater configurations, making its dimensions and capacity particularly relevant for larger families.
This guide covers the Toyota Innova Crysta dimensions, engine specifications, seating capacity, boot space, fuel tank, weight and key features.
Toyota Innova Crysta Dimensions
The Innova Crysta measures 4,735 mm in length, 1,830 mm in width and 1,795 mm in height. It has a 2,750 mm wheelbase and 178 mm of ground clearance.
| Dimension | Measurement |
|---|---|
| Length | 4,735 mm |
| Width | 1,830 mm |
| Height | 1,795 mm |
| Wheelbase | 2,750 mm |
| Ground Clearance | 178 mm |
Toyota Innova Crysta Seating Capacity and Boot Space
The Innova Crysta is available with 7- and 8-seater configurations.
This gives buyers a choice based on their passenger requirements. The 7-seater layout is suited to those who prefer a different seating arrangement, while the 8-seater configuration provides additional passenger capacity.
The MUV has 300 litres of boot space. The usable luggage area depends on the seating arrangement and the size of the items being carried.
For families using the vehicle for everyday travel, shopping or longer journeys, boot capacity becomes an important practical specification.
Toyota Innova Crysta Engine Specifications
The Innova Crysta uses a 2.4-litre, 4-cylinder diesel engine with a displacement of 2,393 cc.
| Engine Specification | Details |
|---|---|
| Engine Type | 2.4L Diesel Engine |
| Displacement | 2,393 cc |
| Cylinders | 4 |
| Max Power | 147.51 bhp @ 3,400 rpm |
| Max Torque | 343 Nm @ 1,400-2,800 rpm |
| Valve Configuration | DOHC |
| Valves Per Cylinder | 4 |
| Fuel Supply System | CRDi |
| Transmission | 5-speed manual |
| Drive Type | Rear-wheel drive |
The engine produces a maximum of 147.51 bhp at 3,400 rpm. Its maximum torque output is 343 Nm between 1,400 and 2,800 rpm.
Torque refers to the rotational force produced by the engine. The Innova Crysta's torque output is relevant to a large MUV because the vehicle is designed to carry several passengers and their luggage.
The engine uses a CRDi fuel supply system and a DOHC valve configuration.
Toyota Innova Crysta Transmission and Drivetrain
The Innova Crysta comes with a 5-speed manual transmission.
A manual transmission allows the driver to select the gears directly using the gear lever and clutch.
The vehicle uses rear-wheel drive (RWD). In this layout, engine power is sent to the rear wheels.
For buyers, the drivetrain is an important specification to consider alongside engine output, vehicle weight and intended usage.
Toyota Innova Crysta Fuel Tank and Kerb Weight
The Innova Crysta has a 55-litre fuel tank. Its kerb weight is approximately 1,735 kg. The combination of a large body, diesel engine and three-row seating makes weight an important specification for the Innova Crysta.
Toyota Innova Crysta Mileage
The provided specification information lists a city mileage figure of around 9 kmpl. Actual fuel efficiency can differ depending on traffic, driving style, road conditions, vehicle load, air-conditioning use, and maintenance.
Toyota Innova Crysta Specifications
The Innova Crysta comes with several features focused on convenience, safety, and everyday usability.
| Feature | Availability |
|---|---|
| Power Steering | Yes |
| Anti-lock Braking System (ABS) | Yes |
| Air Conditioner | Yes |
| Driver Airbag | Yes |
| Passenger Airbag | Yes |
| Automatic Climate Control | Yes |
| Alloy Wheels | Yes |
| Multifunction Steering Wheel | Yes |
| Engine Start-Stop Button | Yes |
These features cover basic driving convenience along with safety-related equipment such as ABS and airbags.
Toyota Innova Crysta Specifications at a Glance
| Specification | Toyota Innova Crysta |
|---|---|
| Body Type | MUV |
| Seating Capacity | 7 or 8 |
| Fuel Type | Diesel |
| Length | 4,735 mm |
| Width | 1,830 mm |
| Height | 1,795 mm |
| Wheelbase | 2,750 mm |
| Ground Clearance | 178 mm |
| Boot Space | 300 litres |
| Fuel Tank Capacity | 55 litres |
| Kerb Weight | 1,735 kg |
| Engine | 2.4L diesel |
| Displacement | 2,393 cc |
| Cylinders | 4 |
| Maximum Power | 147.51 bhp @ 3,400 rpm |
| Maximum Torque | 343 Nm @ 1,400–2,800 rpm |
| Transmission | 5-speed manual |
| Drivetrain | RWD |
What Do the Toyota Innova Crysta Dimensions Mean for Everyday Use?
The dimensions give a better idea of how the Innova Crysta fits into everyday driving.
- 4,735 mm length: Indicates the vehicle's large overall footprint and is relevant when parking.
- 1,830 mm width: Defines the vehicle's lateral dimensions.
- 1,795 mm height: Contributes to its tall MUV profile.
- 2,750 mm wheelbase: Supports the three-row cabin layout and passenger packaging.
- 178 mm ground clearance: Provides clearance over speed breakers and uneven surfaces.
- 300-litre boot: Offers dedicated luggage space.
- 7- or 8-seat capacity: Gives buyers flexibility based on passenger requirements.
Is the Toyota Innova Crysta Suitable for Family Use?
The Innova Crysta's specifications are centred around passenger carrying capacity and practicality. Its 7 or 8 seat layout, three-row configuration and 300-litre boot make it relevant for larger families.
The 2.4-litre diesel engine also produces 343 Nm of torque, while the 55-litre fuel tank supports longer journeys between refuelling stops.
However, the vehicle's large dimensions should be considered when it is primarily used in congested urban areas or tight parking spaces.
Conclusion
The Toyota Innova Crysta dimensions and specifications reflect its positioning as a large MUV. It measures 4,735 mm in length and has a 2,750 mm wheelbase, 178 mm ground clearance, and 300-litre boot space.
Its 2.4-litre diesel engine produces 147.51 bhp and 343 Nm, paired with a 5-speed manual transmission and rear-wheel drive. With 7- and 8-seater configurations, the Innova Crysta offers different seating options for buyers with varying passenger requirements.
Read More: Toyota Innova Crysta Insurance
FAQs
The Innova Crysta is 4,735 mm long, 1,830 mm wide and 1,795 mm high.
The Toyota Innova Crysta has a 2,750 mm wheelbase.
The Innova Crysta has 178 mm of ground clearance.
The Innova Crysta is available in 7- and 8-seater configurations.
The Innova Crysta has 300 litres of boot space.
It uses a 2,393 cc, 2.4-litre 4-cylinder diesel engine.
The engine produces 147.51 bhp at 3,400 rpm and 343 Nm of torque between 1,400 and 2,800 rpm.
The Innova Crysta uses a rear-wheel-drive (RWD) system.
The Toyota Innova Crysta has a 55-litre fuel tank.
